SOLAR PANEL

Harness the natural energy of the sun

Use the sun to your advantage with our Automate® Solar Panel V2. When paired with our solar panel, Wirefree Li-ion & Zero Li-ion motors remain powered by harnessing the natural energy of the sun. The Solar Panel V2 uses industry-leading, crystal technology to maximise sun ray absorption in a wide range of locations and orientations. Renewable power means motors stay running for longer, without the need for regular charging. Efficiently keep spaces warm, or cool with this environmentally friendly upgrade to battery-operated shades.

HOME_half width_PRODUCTSUPPORT_control4_iphone
HOME_half width_PRODUCTSUPPORT_control4_iphone

SOLAR PANEL

Slimline design meets supreme low light performance

  • Renewable power
  • Plug ‘n’ perform power for wirefree motors
  • Multiple mounting points
  • Optimal performance in low light circumstances
  • Crystal technology to increase solar ray absorption
Solar Panel

Technical Specifications

Show Specifications Hide Specifications

5V Solar Panel
Imax (USB Connector) 600mA
IP Rating IP40
Max Output Power 3W (Under 1 SUN - 1200W/m²)
Temp Working Range 32°F to 140°F (0°C to 60°C)
Vmax (USB Connector) 5 V

AUTOMATE | DC POWER DISTRIBUTION PANEL

Powers up to 18 DC motors

Higher 15V output allows for greater cable lengths from motor to power panel, freeing up routing options within an installation. Removes the need for multiple individual power adaptors for each DC motor in an installation, combining each power source into a single location. Channels may also be wired in parallel to provide additional power to larger motors.

  • Capacity for up to 18 ARC DC motors (18mm, 25mm, and 28mm motors)
  • Ability to parallel connect motor supplies for higher current motors (35mm
    and 45mm motors)
  • LED status indication for checking whether power is being applied to panel
  • LED status indication for each individual motor supply
DC Dist Panel

Technical Specifications

Show Specifications Hide Specifications

DC Power Distribution Panel
Ingress Protection IP40
Input Voltage Range 85-125 VAC (US) / 85-245 VAC (AUS)
Maximum Output Current (all 18 channels) 24 A
Output Voltage Range 15 VDC
Power Output Rating 360 W
Single Channel Absolute Maximum Current Output 1.33 A

RECHARGEABLE BATTERY PACK

Continuous power

Enables Automate DC motors to operate wirelessly and without the constraints of traditional battery wands with disposable batteries.

  • Replaces battery wand with replaceable batteries
  • Provides up to 500 up/down cycles on a single charge (depends on shade size & fabric weight)
  • Compatible with Automate Cord Lift, Venetian Tilt, 18, 25 & 28mm tubular DC motors
  • Small profile allows for optimal placement in window pocket
  • Battery pack fully recharges in ~ 6 hours
  • Battery health status reported in Automate Pulse App
  • Pairs with optional solar panel for autonomous re-charging
Battery Pack

Technical Specifications

Show Specifications Hide Specifications

Rechargeable Battery Pack 12V
Battery Size/Type 1-1/4” x 1-1/4” x 10” / Lithium-ion Rechargeable
Input Voltage Range 12.6V
Insulation Class III
Output Voltage Range 12.0V
Temp Working Range 32F - 140F

automate repeater

Power to increase the range

If you have an instance whereby not all motors are responding or responding intermittently, the ARC repeater will double the range you currently get.

  • Increases the range up to 40m/131f
  • perfect for double story home or multi level buildings
  • Easy to use Plug & Play
  • No pairing or configuration
  • Maximum 2 Repeaters per system / network
  • Bi-directional (receives motor feedback)
Accessories

Technical Specifications

Show Specifications Hide Specifications

ARC Repeater
Color/Colour White
Indicator Blue LED
IP Rating IP45
Storage Temperature 14 ~ 149 °F (-10 ~ 65 °C)
Weight 0.01 kg / 0.022 lbs
Working Humidity < 80%
Working Temperature 23 ~ 122 °F (-5 ~ 50 °C )

ARC RELAY MODULE

Your smart interface

Our AUTOMATE ARC Relay Module acts as an interface between smart systems & Automate ARC motors. Offering wireless control and features up, down & stop contact inputs.

  • Interface between third party smart home systems and ARC motors
  • Three contact inputs – Up, Down & Stop
  • Wireless control of ARC motors
  • Roller mode and Step mode for Venetian motors
  • Group Motor Control
  • 12V or 24V power source compatible
Accessories

Technical Specifications

Show Specifications Hide Specifications

ARC Relay Module
Radio Frequency 433.92 MHz
Temp Working Range -10°C ~ 50°C
Transmission Distance Up to 200m (open space)
Transmitting Power 10 milliwatt
Voltage 16V ~ 26V

Dc power supply



  • 100W switch mode power supply
  • Laptop type power supply
  • Includes AU plug
DC Power_US

Dimensions

Show Specifications

DC Power Supply
Cable Length 240V = 1800mm & 12V = 1500mm
Length (x) 107mm
Thickness 34mm
Width 48mm

zero Li-ion 5V Charger

Easy and convenient self-charge device.

  • Charges latest Zero Li-ion 5V Motor range
  • Features a 2 Amp USB power supply
  • 4m Micro USB cable supplied.
Accessories

Li-ion 12V Charger

Easy and convenient self-charge device.

  • Charges original Li-ion 12V Motor range
  • Requires 6 hours initial charge time
  • 1.2m cord
  • Built-in battery charge indicator
DC Power_AU

Extension cables 12V

  • Used with Li-Ion 12V motors
  • Comes in three convenient sizes; 155mm, 1.2m & 2.4m
  • Extension cords provide additional length for the charge cable to reach power points.
12V Charger

Extension cables 5V

  • Used with Zero Li-Ion 5V motors
  • Comes in three convenient sizes; 155mm, 1.2m & 2.4m
  • Extension cords provide additional length for the charge cable to reach power points.
5V Charger

DC FT Extension Cables

  • Extension cables provide additional length for installing the Battery Pack for DC FT15 Motor
  • Comes in two sizes: 250mm and 3m
External battery motor cable extension

DC FT Battery Pack

  • Provides up to 6 months usage on a single charge ( shade size, fabric weight & usage dependant)
  • Battery pack fully recharges in ~ 7 hours
  • Battery health status can be viewed in the Automate Pulse App
External Battery Pack - Hero
