PRODUCT CHANGE | E6, M6 & In-line Connector wiring structure

14th February 2022

PRODUCT DETAILS

DESCRIPTION. AUTOMATE | E6 [35mm/6.0Nm/28r] ACR-MTR240V AUTOMATE | M6 [35mm/6.0Nm/28rpm] S45ML MOTOR AUTOMATE | C – ARC DRAPE MOTOR 50KG [240V/9rpm]
Wiring Layout GEN2 GEN2 GEN1
CODE. MTACRF35-6-240V RB24-4502-069003 MT01-2101-069001
IMAGE.
USE WITH. UNIVERSAL in-line tail 2.5m & UNIVERSAL in-line tail 5.0m

DISCONTINUED PRODUCT DETAILS

DESCRIPTION. AUTOMATE | UNIVERSAL in-line
tail 2.5m
AUTOMATE | UNIVERSAL in-line tail 5.0m
CODE. RB24-9104-069025 RB24-9104-069050
IMAGE.

Production/Installation Improvements:

  • Change to the wiring layout to standardise to universal
  • Cables that are supplied with the motor in the box will be compatible with each other.
  • An issue may arise with pre-wired installations if motor wiring layout and pre-installed universal tails are not compatible
  • Please verify that the wiring is compatible before installing the motor.
