SOLAR PANEL v1
The original Automate Solar Panel provided power to our range of Wirefree Li-ion battery motors.
- Plug ‘n’ play for all AUTOMATE Li-ion motors & rechargeable battery packs
- Sleek design allows for unobtrusive placement behind most headrails
- Parallel wiring options support large shades
Technical Specifications
Show Specifications Hide Specifications
| Solar Panel V1 | |
| Max Average Current | 190 ± 20 mA |
| Max Average Voltage Output | 12.3 ± 0.1 V |
| Minimum Lux Value | 10 ± 5 KLux |
| Power Output | 2.3 ± 0.2 W |
PULSE 1 HUB
The original Pulse 1 hub, offering smart phone control for motorised shades.
- ARC compatible
- Set up to 20 scenes and timers.
- Control from anywhere right from your phone.
- Step by step set up wizard
- Compatible with Alexa voice assistant.
Technical Specifications
Show Specifications Hide Specifications
| Pulse v 1 | |
| Antenna | Built-in |
| Current | 500mA |
| Device Control Frequency | 433MHz |
| Installation | Desktop or wall-mounted |
| Power | <2.5W |
| Power Input | 5VDC/1A |
| Protection Class | IP20 |
| Radio Coverage | 30m for device control (indoors) |
| Standby Power | ≤300mA |
| Storage Temperature | -20⁰ to 55⁰ |
| Wi-Fi Network | 802.11 b/g/n 2.4GHz |
| Working Temperature | -10⁰ to 45⁰ |
A20 Awning Motor
The Automate A20 offers a complete motorised solution for smaller cassette style awnings, such as ILIOS Pivot Arm and Wire Guide systems.
- Advanced self-tightening fabric technology
- Favorite position setting
- Simplified set up
Technical Specifications
Show Specifications Hide Specifications
| A 20 | |
| Diameter | 45mm |
| Max Run Time | 4min |
| Protection Class | IP44 |
| Radio Frequency | 50Hz |
| Rated Power | 228W |
| Speed | 15rpm |
| Torque | 20Nm |
| Voltage | 230V |
RF200 Series Remote Gen 1
Technical Specifications
Show Specifications Hide Specifications
| RF200 Series Remote Gen 1 | |
| Capacity | 1.1Nm |
| Current | 0.8 amps |
| Protective Rating | IP40 |
| RPM | 25 |
| Transmitting Frequency | 433.92MHz |
| Volts | 7 |
RF200 Series Remote Gen 2rf200
Technical Specifications
Show Specifications Hide Specifications
| RF200 Series Remote Gen 2 | |
| Capacity | 1.1Nm |
| Current | 0.8amps |
| Device Control Frequency | 433.92MHz |
| Protective Rating | IP40 |
| RPM | 25 |
| Volts | 7V |
RF200 Series Remote Gen 3
Technical Specifications
Show Specifications
| RF200 Series Remote Gen 3 | |
| Radio Frequency | 433.92MHz |
| Transmission Distance | 200m |
| Transmitting Power | 5 mill wat |
| Voltage | 3V |
RF500 Series Remote Gen1
Technical Specifications
Show Specifications Hide Specifications
RF500 Series Remote Gen2
Technical Specifications
Show Specifications Hide Specifications
RF500 Series Remote Gen3
Technical Specifications
Show Specifications Hide Specifications
RF500 Series Remote Gen4
Automate RF500s series offers a single & fifteen channel 433MHz hand held transmitter controller compatible with the AUTOMATE EL motor range. It includes a hidden intercatie channel, touch senstivive controls & a slimline magnetic wall mount holder.
Technical Specifications
Show Specifications Hide Specifications
| RF500 Series Remote Gen 4 | |
| Device Control Frequency | 433.92MHz |
| Operating Temperature | -10 degrees celsius - 50 degrees celsius |
| Transmission Distance | up to 200m (open space) |
| Transmitting Power | 10 milliwatt |
| Voltage | 3V |
RF401 Remote
Automate RF401s is a single channel 433MHz wall mounted controller compatible with the AUTOMATE EL motor range. It includes a daily timer function and Large LCD screen.
Technical Specifications
Show Specifications Hide Specifications
RF415 Remote
Automate RF415s is a fifteen channel 433MHz wall mounted controller compatible with the AUTOMATE EL motor range. It includes a large LCD display, hidden interactive channel feature & slimline magnetic wall mount.
Technical Specifications
Show Specifications Hide Specifications
Wind & Sun Sensor Gen1
- A.R.T. (AUTOMATE REACTIVE TECHNOLOGY) Solar powered Wind & Light sensor with built in Lithium Ion Battery.
- Compatible with AUTOMATE motors and controllers.
- Suitable for monitoring Wind & light intensity and reacting according to pre selected settings to control motorised awnings or external blinds
- 3 x Wind speed sensitivities.
- 4x Light intensity levels.
Technical Specifications
Show Specifications Hide Specifications
| Wind and Sun Sensor Gen 1 | |
| Device Control Frequency | 433MHz |
| Operating Temperature | -5 degrees celsius - 60 degrees celsius |
| Transmission Distance | up to 200m (open space) |
| Transmitting Power | 10 milliwatt |
| Voltage | 3V |
FT Motor Gen1
- AUTOMATE | FT MOTOR is a multifunction tubular motor offering three different modes of operation;
- E-type for standard use
- MANUAL FT Mode for use with conventional locking devices with fabric tensioning
- AUTO FT Mode for use with Rollease Acmeda’s proprietary ULTRA LOCK providing automatic fabric tensioning.
- Activating fabric tension (FT) mode delivers a choice of 3 distinct tensioning levels to suit a wide range of sizes and external applications. Functional options in each operating mode include; IMPACT DETECTION & FAVOURITE POSITION.
- Impact detection senses an obstacle in the blinds path and redirects the blind to protect the motor, hardware and fabric, ensuring product longevity. An intermediate setting allows for a customised favorite position to be pre-set.
Technical Specifications
Show Specifications Hide Specifications
| FT Motor Gen 1 | |
| Current | 140W |
| Diameter with Automate Motor Cap (sold separately) | 45mm |
| Input Voltage AC Module | 220-240V AC |
| Max Run Time | 4 mins |
| Protection Class | IP44 |
| Rated Power | 0.61A |
| Speed | 15rpm |
| Torque | 15Nm |
| Transmitting Frequency | 433.92 MHz |
| Weight | 1.98kg |
PARADIGM REMOTE CONTROLS
Automate Paradigm remotes feature a contemporary design with touch sensitive controls.
- Available in single and fifteen channel models
- Touch sensitive buttons
- Leveling control & LCD display (15 channel remote only)
- Hide unused channel function
- Optional slim magnetic wall mount
Technical Specifications
Show Specifications Hide Specifications
| Single & Fifteen Channel | |
| Device Control Frequency | 433.92 MHz |
| Operating Temperature | -10°C -50°C |
| Transmitting Power | 10 milliwatt |
| Typical Transmission Distance | 20 meters (65 feet) |
| Voltage | 3V (CR2450) |
ac 240V Motors
Automate Drapery Motor
This motor can provide continuous power to motorise curtains up to 11 metres wide with fabric weighing just over 50 Kg’s.
Features
Manual Activation
Gently pull on the drape fabric and the motor will complete the action automatically moving the drapes to the preferred, open or closed, position.
Soft Stop
Motor will slow down so that drapes come together softly, upon closure, for a refined aesthetic.
Bidirectional Communication
Automate Radio Communication utilizes two-way communication to provide up-to-date feedback on shade positioning via the Automate Pulse 2 app.
Adjustable Speed Control
Three shade speed settings to suit your needs faster for larger shades, slower for smaller. Features quiet operation when set to the lowest speed setting.
Simplified Setup
Whether using a remote control or app for shade setup, Automate programming instructions are streamlined to have your shades moving as quickly as possible.
Technical Specifications
Show Specifications Hide Specifications
| Drapery Motor | |
| Amps | 0.2 A |
| Insulation Class | II |
| IP Rating | IP40 |
| Limit Switch Type | Electronic |
| Max Run Time | 12 Min |
| Radio Frequency | 433.92 MHz |
| RF Modulation | FSK |
| Sound Level | ~44 DB |
| Speed | 120 RPM (Adjustable to 100 or 80) |
| Temp Working Range | 32°F to 140°F (0°C to 60°C) |
| Torque | 1.2 Nm |
| Voltage | 110-240 V AC |
Controllers
Paradigm +
View DetailsParadigm Wall Switch
View DetailsPulse 2 App
View DetailsPulse 2 Hub
View DetailsPush5 Remote
View DetailsPush15
View DetailsAccessories
ARC Repeater
View DetailsARC Relay Module
View DetailsPARADIGM Plus REMOTE CONTROL
The Paradigm Plus remote features a contemporary design with tactile push button controls.
- Available in fifteen channels
- Push button controls
- Leveling control & LCD display
- Hide unused channel function
- Optional slim magnetic wall mount
Technical Specifications
Show Specifications Hide Specifications
| Fifteen Channel | ||
| Device Control Frequency | 433.92 MHz | |
| Operating Temperature | -10°C -50°C | |
| Transmission Distance | 20 Meters typical (Up to 100 Meters unobstructed) | |
| Transmitting Power | 10 milliwatt | |
| Voltage | 3V (CR2450) |
